Features

• Pico 60 A AC/DC Current Probe TA009, 4 mm (Banana) Plug Connector. Pico TA009 current probe can measure currents from 10mA up to 60A with a switch selectable high and low range. When measuring DC current, a simple push button is included for zero adjustment. This current probe is equipped with 4 mm connectors compatible with multimeters. Input ranges (DC): Low (1mV/10mA) 10mA to 20A; High (1mV/100mA): 100mA to 60A Input ranges (AC RMS): Low (1mV/10mA) 10mA to 20A; High (1mV/100mA) 100mA to 60A AC frequency range up to 20kHz Maximum conductor size 9mm Output connectors 4 mm banana plugs Operating environment 0 to +50 °C, 70% RH Battery type 9 V DC NEDA 1604, 6F22, 006P Battery life 100 hours typical with alkaline Dimensions 195 x 70 x 33 mm
