63-4171-86 ［Discontinued］Ultrasonic thickness gauge STG-01U
Product Description
Product Model: 63-4171-86Product Brand: CUSTOM corporat […]
Contact Us
Product Details
Product Model: 63-4171-86
Product Brand: CUSTOM corporation
Features
- It can measure the thickness of various materials from metals to non-metals (Glass, resin, etc.).
- Measure objects with a thickness of 1.2 mm to 220 mm in 0.1 mm increments.
- As a non-destructive tester, it can be ***d to identify corrosion and defects in the object to be measured.
Spec
- Measurement Method: Ultrasonic Pulse Reflection Type
- Sampling: approx. 2 times/second
- Measurement Range: 1.2~220 mm (Steel)/Minimum Pipe Size: Outer Diameter φ20 mm, Wall Thickness 3 mm (Steel)
- Resolution: 0.1 mm
- Accuracy: ± (1%rdg+0.1) mm
- Sound speed design range: 1000~9999 m/s
- Probe: Integrated Cable Type (Cable length approx. 950 mm, weight approx. 46 g)/Operating Frequency: 5 MHz/Outer Diameter (Contact Surface Diameter): φ18 mm (φ10 mm)
- display: 4-digit LCD
- Memory: Up to 10 items
- Power supply: 3 AA batteries (included for testing)
- Battery Life: Approximately 12 hours (when using alkaline batteries)
- Auto Power Off: Approx. 2 minutes
- Operating temperature and humidity: 0~+40°C, 80%RH or less (no condensation)
- Storage temperature and humidity: 0~+40°C, 20~80%RH (no condensation)
- Dimensions: Approx. 72 x D36 x H135mm
- Weight: about 170 g(excluding batteries and probes)
- Accessories: Probe (φ10 mm/5 MHz), Test Piece, Couplant, Hard Case, Instruction Manual, AA Batteries x 3 (for Testing)
