3-3946-21 Fume Hood (Open Dive Ceramic Top Plate) Standard 1200 x 830 x 2250 mm ABS-1200C
Product Description
Product Model: 3-3946-21Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3946-21
Product Brand: AS ONE Corporation
Features
- The trestle is an open type and the cooling water circulation device is also convenient for combining with equipment such as vacuum pumps.
- The air volume display function is provided as standard, and the exhaust condition can be checked and operated.
- The work surface is a ceramic top plate with excellent wide chemical resistance and heat resistance.
- For Acid/Alkali
- For Organic
Spec
- Specifications: Standard
- External Dimensions (mm): 1200 x 830 x 2250
- Inner Dimensions (mm): 950 x 605 x 1200
- Weight (approx. kg): 280
- Exterior: Steel (Powder Coating Finish)
- Interior: Chemical-Resistant/Heat-Resistant Board (Flame-Retardant Material/Phenolic Resin Laminated Board)
- Work Surface: Epoxy Resin Top Plate Integrally Molded Product (32 mm Thick) or Chemical-Resistant Ceramic Top Plate Integrally Molded Product (33 mm Thick)
- Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Limiting Key (H400 mm), Handle/ABS Resin
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
