3-3945-31 Fume Hood (Variable Air Volume VAV Type) Standard 1200 x 830 x 2250 mm ABSV-1200
Product Description
Product Model: 3-3945-31Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3945-31
Product Brand: AS ONE Corporation
Features
- The controlled wind speed is always kept constant in conjunction with the sash opening to achieve safety, energy saving and comfort at the same time.
- The exhaust air volume is automatically controlled continuously according to the movement of the sash, and the exhaust air volume can be reduced up to 1/4 when the sash is closed.
- While the sash is closed, wasteful exhaust can be suppressed, saving energy.
- Surface velocity display (m/s) is possible.
- For Acid/Alkali
- For Organic
Spec
- Specifications: Standard
- External Dimensions (mm): 1200 x 830 x 2250
- Inner Dimensions (mm): 950 x 605 x 1200
- Weight (approx. kg): 275
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
- Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Limiting Key (Height 400 mm), Handle/ABS Resin
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected earths)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- Automatic Air Flow Control: Full Scale Automatic Exhaust Air Flow Control Equipped
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
