3-3938-21 Fume Hood (PVC Fan Top Mounted Type) Standard 1200 x 830 x 2250 mm ABSF-1200
Product Description
Product Model: 3-3938-21Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3938-21
Product Brand: AS ONE Corporation
Features
- A type equipped with a PVC fan as standard.
- By mounting the exhaust fan on the top of the hood, the installation cost and labor of the exhaust fan can be saved.
- Equipped with air volume display function as standard, it is possible to check the exhaust condition and work.
- With Exhaust Fan
- For Acid/Alkali
- For Organic
Spec
- Specifications: Standard
- External Dimensions (mm): 1200 x 830 x 2250
- Inner Dimensions (mm): 950 x 605 x 1200
- Weight (approx. kg): 305
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Painted Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
- Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Restriction Key (Height 400 mm), Handle/ABS Resin
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- Exhaust Fan: Top Mounted PVC Motor Direct-Connected Power Supply/Φ3 200 V
- [Exhaust]
- Air volume (m3/min): 13
- Duct Connection Port: 200 A
- Required Duct Diameter (φmm): 200
- [Exhaust Fan]
- Type: No. 200
- Motor (kW): 0.4
- Attached Facility: Fluorescent Lamp (Piece)/20 W x 2 Lamps Equivalent
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *If the duct distance is long or the number of turns is large, the fan capacity may be insufficient.
