3-3936-31 Fume Hood (FRP Fan Equipped/Inverter Type) Standard 1200 x 830 x 2250 mm ABSF-1200INV
Product Description
Product Model: 3-3936-31Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3936-31
Product Brand: AS ONE Corporation
Features
- Equipped with an inverter, the exhaust air volume and static pressure can be flexibly changed even after installation.
- Equipped with air volume display function as standard, it is possible to check the exhaust condition and work.
- With Exhaust Fan
- For Acid/Alkali
- For Organic
Spec
- Specifications: Standard
- External Dimensions (mm): 1200 x 830 x 2250
- Inner Dimensions (mm): 950 x 605 x 1200
- Weight (approx. kg): 305
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
- Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Limiting Key (Height 400 mm), Handle/ABS Resin
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power Supply Connection: Terminal Block with Electric Box
- Exhaust Fan: Top-Mounted FRP Motor Direct Connection Type/100KSS-O Power Supply/3Φ 200 V Motor/0.4 kW
- [Exhaust]
- Air volume (m3/min): 13
- Duct Connection Port: 200 A
- Required Duct Diameter (φmm): 200
- Attached Facility: Fluorescent Lamp (Piece)/20 W x 2 Lamps Equivalent
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *If the duct distance is long or the number of turns is large, the fan capacity may be insufficient.
