62-9147-12 ［Discontinued］Phase Sequence Indicator (With Voltmeter) EA711-11
Product Description
Product Model: 62-9147-12Product Brand: ESCO Company Lt […]
Contact Us
Product Details
Product Model: 62-9147-12
Product Brand: ESCO Company Ltd.
Features
- Hold function, battery check, auto power off
- With cell phone case
- Non-contact type allows phase inspection from the top of covered wires.
- The phase order, ground phase, and three-phase voltage values are displayed simultaneously on the display.
Spec
- Wide Type 、 IV・HIV:8 to 325m㎡ CV:2 to 250m㎡ Correspondence
- Working Voltage Range …Three phases of soil AC90 to 520V
- Working Frequency Range …45 to 66Hz
- Phase Display …(Positive phase):Screen POS Display ＋Yellow Green Color Backlight 、Intermittent Buzzer Sound (Reversed phase):Screen REV Display ＋Red Color Backlight 、Continuation Buzzer Sound (Other):Phase unexpected prediction, Ground phase prediction
- Hold Function 、Battery Check、Auto Power Off
- Power Supply…AA Battery x 4 Pcs (included)
- Size …Body :84(W) x 46(D) x 146(H)mm Cable Length :0.5m
- Weight …590g
- With Mobile Case
- It is non-contact type and can detect the phase from over the sheathed wires.
- It indicates the order of phases, grounding phase, and 3-phase voltage value on the display at the same time.
