62-0955-43 ［Discontinued］Digital Flow Meter 2 - 100L/Min IDS-100F
Product Description
Product Model: 62-0955-43Product Brand: IAC Features Av […]
Contact Us
Product Details
Product Model: 62-0955-43
Product Brand: IAC
Features
- Available fluids are dry air, nitrogen, argon and carbon dioxide.
- The power supply is an AC outlet of 100 V, so it can be ***d immediately.
- Repeatability is less than ±1%F.S.
- The flow control valve is integrated, and the flow rate can be adjusted.
- Rear piping for easy piping.
- Hollow fiber filter for contamination prevention is standard.
Spec
- Model number: IDS-100F
- Fluid ***d: Dry air, N2, Ar, CO2
- Flow rate range: 2 - 100L/min (in the case of CO2, 1/2 of the left)
- Accuracy: ±3% F.S. or below (with dry air)
- Display unit: Instantaneous Flow rate (L/min), Integrating flow (L)
- Tube bore: Rc1/4 female screw (both outlet/inlet)
- Power supply: AC100V
- Size: 110 x 220 x 80mm (when hollow fiber filter is mounted)
- Weight: 1.2kg
