3-5821-01 ［Discontinued］Laboratory Bench Hood Single-Sided Type, Made Of Aluminum Slide Sash Type 1200 x 750 x 1400 TSS-1200
model:
3-5821-01
category:
gasmonitors
Product Description
Product Model: 3-5821-01 Features Equipment and equipme […]
Contact Us
Product Details
Product Model: 3-5821-01
Features
- Equipment and equipment installed on a laboratory bench. This hood is ***d to exhaust small amounts of harmful gases.
- Opening and closing door using aluminum form and tempered glass.
- The inside of the hood is wide and transparent, so the field of view is wide and it is easy to observe inside.
Spec
- Frame: Strengthened aluminum type material, Corrosion resistant anodic oxide coating treatment
- Front door: Transparent strengthened glass (5mm thick) TVS type/balance weight type, TSS type/slide type
- Side and back: Transparent strengthened glass (5mm thick), Fixed window
- Ceiling plane: Transparent hard PVC (vinyl chloride resin)
- Exhaust duct: Hard PVC (vinyl chloride resin), with volume damper
- Specification: Slide sash type
- Outer dimension (mm): 1200 x 750 x 1400
- Front door (sheet): 2
- Exhaust air volume (m3/min): 11
- Exhaust connection port Size (φmm): 200
- Model number: TSS-1200
- *Transportation cost, carrying cost, installation cost, assembly cost, etc. are required separately. Please contact with us. *Air volume is the recomm***ed value in case controlled wind speed is 0.5 m/s when the front door (TSS type is only 1 sheet) is half-open. *Regarding drawing of TSS type, please contact us.
