Spec

• Display method: Digital display, Red color 7 segments LED, 1 + 3 digits (height of characters is 10mm), Display by front key
• Display type: Output value, Control input value, Upper limit (gradient) external settings, Lower limit external settings,
• Setting method: Dep***ing on front key and external mounting variable resistance instrument
• Selection of control system: Phase control angle, Phase control voltage square, 0 cross switching cycle calculation control
• Upper limit (gradient) settings: 0 - 100%
• Lower limit settings: 0 - 100%
• Soft start timer settings: 0 - 25.0s
• Slow up timer settings: 0 - 25.0s
• Slowdown timer settings: 0 - 25.0s
• Input type selection: Voltage, Current, Contact, Voltage pulse
• Input sampling cycle settings: 0 and 1 - 120s (contact and voltage pulse input type corresponds 2 positions operating with 0s settings, Correspond to proportional operating at 1s or more set to multiple of controller proportional period time)
• Rating voltage: AC90 - 264V (free power)
• Rated frequency 45 - 65Hz
• Input type: Current, Voltage, Contact, Voltage pulse (SSR drive voltage)
• Sampling cycle: Contact and voltage pulse input/2ms at 2 positions operating 1 - 120s at proportional operating, Current and voltage input/2 (control power frequency)
• Current capacity: 100A
• Output range: 0 - 98% or more of input voltage
• Control system 3 types: Phase control angle, Phase control voltage square, 0 cross switching cycle calculation control
• Minimum load current: 0.5A (output 98%)
• Applied load: Phase control/resistance load, 0 cross switching cycle calculation control/constant resistance load
• External setting variable resistance instrument: Upper limit (gradient)/0 - 100% (B10kΩ), Lower limit/0 - 100% (B10kΩ)
• Fast-blow f***: External installation
• Data retention: EEPROM (nonvolatile memory)
• Usage environment conditions: Temperature/0 - 55℃ (operation guarantee range) 0 - 40℃ (performance guarantee range), Humidity/90%Rh or less (no condensing), Elevation/altitude 2000m or less, Category/II, Pollution degree/2
• Input noise rejection ratio: Normal/50dB or more, Common/100dB or more
• Insulation resistance: Between input and power/20MΩ or more DC500V (1 minute), Between input and chassis/20MΩ or more DC500V (1 minute),
• Withstand voltage: Between input and output/AC2300V (1 minute), Between input and chassis/AC1500V (1 minute)
• Storage temperature: -20 - 65℃
• Mass: Approx 2.3kg
• Cooling method: Natural air cooling
• Outer dimensions (Width x Depth x Height mm): 155 x 154 x 192.5
