3-5335-21 ［Discontinued］Compact Draft Standard Fan Specification with Feed Drainage CD9S-W
model:
3-5335-21
category:
gasmonitors
Product Description
Product Model: 3-5335-21 Features Wide work surface mak […]
Contact Us
Product Details
Product Model: 3-5335-21
Features
- Wide work surface makes it easy to work in drafts.
- A draft with an activated carbon adsorption filter.
- The adsorbent can be selected according to the target gas and can be processed with high removal efficiency.
- The adsorbent is of the capsule cartridge type and can be easily attached and replaced.
- The door is a balance weight system and can be stopped at any position in the vertical direction.
- The inverter type adopts a motor fan with an inverter control system, and the exhaust air volume can be adjusted.
Spec
- Material: Body, scrubber/stainless steel (SUS304), Body/PVC (vinyl chloride resin)
- Outer dimensions: 1200 x 715 x 1873mm
- Effective internal dimensions: 898 x 608 x 800mm
- Sash opening: 820 x 625mm
- Evenly load-bearing Work plane/50kg, Inner frame/50kg
- Internal lighting: Fluorescent lamps (15W) x 1 piece
- Operation volume: Approximately 80dB
- Surface speed: About 0.5m/s (door 1/2 opening)
- Exhaust air volume: About 8m3/min (door 1/2 opening)
- *Possible to change dep***ing on the working environment
- Power supply: AC100V 50/60Hz 15A
- Power cord length: 2.5m
- Service outlet: 100VAC 3P x 2 pieces, maximum 8A is available
- Weight: Approx 160kg
- Conform duct diameter: φ200mm
- Supply water connection port: Rp1/2 (outer diameter φ16mm bamboo included)
- Accessories: Feed/drainage hose 2m x 1 each
- Model number: CD9S-W
- Standard fan
- Feed drainage: There
- Stainless steel, dry scrubber Integral type
- *Replacement activated carbon filter for neutral gas for 4GM is included.
