3-5287-01 ［Discontinued］Double-Sided Clean Bench CTW-900UVAD
model:
3-5287-01
category:
gasmonitors
Product Description
Product Model: 3-5287-01 Features Keeps environment ins […]
Contact Us
Product Details
Product Model: 3-5287-01
Features
- Keeps environment inside booth clean with clean air by removing 99.97％ or more of 0.3*um* and larger particles with antibacterial/deodorant HEPA filter.
- This compact and low cost clean bench provides locally clean environment.
- Equipped with sterilization lamp to sterilize inside of booth.
- Efficient since two people can work at the same time.※Air blown out from top face flows dep***ing on door opening degree. There is no partitioner such as air curtain inside space.
Spec
- Model number: CTW-900UVAD
- Size (mm): 900 x 764.7 x 811
- Effective work plane dimensions (mm): 814 x 614
- Material: Work plane/stainless steel (SUS304), Side window and front door/PC (polycarbonate), Frame/aluminum)
- Pre-filter: Modal acrylic/polyester
- Dust collection effect: 99.97% or more (0.3um particle)
- Power supply: AC100V 50/60Hz, Cord length/1.5m (3P plug and OA adapter included)
- HEPA filter (mm): 200 x 200 (2 sheets)
- Air volume processed (m3/min): 2.0
- Blowing wind velocity (m/s): 0.6
- Power consumption (W): 138
- Lighting (W): Fluorescent lamp 15W x 2 lamps, Sterilization lamp 15W x 1 lamp
- Weight (kg): 45.6
- Opening air volume (m3/min) *1: 1.1
- Air cleanliness (class) *2: 100
*This product might require extra fees.
