gasmonitors
3-4516-01 ［Discontinued］ASSRE Fume Hood for Processing Perchloric Acid Processing, Heating Oxidative Decomposition Type 1200 x 995/900 x 2250 ADB-1200
model:
3-4516-01
category:
gasmonitors
Product Description
Product Model: 3-4516-01 Features It comes with a hot p […]
Contact Us
Product Details
Product Model: 3-4516-01
Features
- It comes with a hot plate ***d for heat treatment with perchloric acid (HClO4) and a stand for cooling the heated beaker, etc., so you can *** it conveniently.
- Since perchloric acid (HClO4) poses a risk of fire and explosion if it coexists with organic substances, an exhaust chamber is provided at the top, and a shower device is installed so that the inside can be cleaned periodically.
- Also suitable for heated oxidative decomposition.
- Since the sash is usually opened for acid treatment, etc., the surface speed of 0.5 m/s is secured at the sash opening position of 550 mm, and it is fixed so that the sash does not close from this position, but it can be released.
- Since the beaker can be stored inside the hood, it can be ***d safely without harmful gas leaking to the outside of the hood.
Spec
- Exterior: Steel (powder coating)
- Interior: Chemical resistance and Heat resistance board (chemical resistant paint baking asbestos-free calcium silicate plate (incombustible material) and Phenol resin laminated sheet plate (oxygen Index = 31.6 Flame retardant material))
- Work planes: Epoxy resin molding (32mm thickness)
- Sash: Transparent strengthened glass (5mm-thick) Balance weights method with sash stopper mechanism
- Supply water plug: Remote control method (polyester resin baking coating)
- Lighting devices: Using fluorescent lamps, with switch
- Outlet AC 100V15A double x 2 pieces included
- Hot plate: Steel and silver coating, with cast gas burner
- Table for beaker and others: Steel and silver coating, Top board/heat resistance and tolerability board
- Exhaust chamber: PVC (vinyl chloride resin)
- Shower device: Remote operation by side post, valve operation, washing water is discharged into cup sink by pipe
-
- Surface speed (m/s) 400mm opening: 0.5
- Air volume (m3/min): 17
- Connection port (φmm): 250
- Duct diameter (φmm): 250
-
- Hot plate: 2
- Beaker table: 1
- Shower device: 1
- Gas cock: 2
- Feed drainage: 1
- Fluorescent lamps (volume): 20W x 2
- Outer dimension (mm): 1200 x 995/900 x 2250
- Inner dimension (mm): 950 x 755 x 1200
- Weight (kg): 365
- Model number: ADB-1200
- *Transportation cost, carrying cost, installation cost, assembly cost, etc. are required separately. Please contact with us.
