3-2115-01 ［Discontinued］ASSRE Fume Hood for High Line Type Organic Synthesis Experiment 1200 x 845/750 x 2550 ASC-1200
model:
3-2115-01
category:
gasmonitors
Product Description
Product Model: 3-2115-01 Features The ceiling height in […]
Contact Us
Product Details
Product Model: 3-2115-01
Features
- The ceiling height inside the fume hood is 300 mm higher than that of the standard type, making it suitable for *** with large laboratory equipment and tall laboratory equipment.
- The glass of the front sash is raised, so you can easily observe the inside of the hood.
- With a sash stopper mechanism, the exhaust air volume is the same as the standard type.
- A surface speed indicator is included so you can work more safely.
Spec
- Exterior: Steel (powder coating)
- Interior: Chemical resistance and Heat resistance board (chemical resistant paint baking asbestos-free calcium silicate plate (incombustible material) and Phenol resin laminated sheet plate (oxygen Index = 31.6 Flame retardant material))
- Work planes: Epoxy resin molding (32mm thickness)
- Sash: Transparent strengthened glass (5mm-thick) Balance weights method with sash stopper mechanism
- Supply water plug: Remote control method (polyester resin baking coating)
- Lighting devices: Using fluorescent lamps, with switch
-
- Surface speed (m/s) 400mm opening: 0.5
- Air volume (m3/min): 12
- Connection port size (mm): φ200
- Duct diameter (φmm): 200
-
Feed drainage
- : 1
- Fluorescent lamps (volume): 20W x 2
- Outlet AC 100V15A double x 2 pieces included
- With surface speed indicator
- Outer dimension (mm): 1200 x 845/750 x 2550
- Inner dimension (mm): 950 x 605 x 1500
- Weight (kg): 295
- Model number: ASC-1200
- *Transportation cost, carrying cost, installation cost, assembly cost, etc. are required separately. Please contact with us.
