gasmonitors
3-2107-01 ［Discontinued］ASSRE Fume Hood Type Equipped with Exhaust Fan 1200 x 845/750 x 2250 ASF-1200
model:
3-2107-01
category:
gasmonitors
Product Description
Product Model: 3-2107-01 Features This type has an exha […]
Contact Us
Product Details
Product Model: 3-2107-01
Features
- This type has an exhaust fan mounted on the top of the fume hood and is suitable when there is no space for the exhaust fan.
- The exhaust fan is made of PVC and is directly connected to the motor and has a compact shape (if it is outside the capability range, it needs to be selected separately).
- A surface speed indicator is included so you can work more safely.
Spec
- Exterior: Steel (powder coating)
- Interior: Chemical resistance and Heat resistance board (chemical resistant paint baking asbestos-free calcium silicate plate (incombustible material) and Phenol resin laminated sheet plate (oxygen Index = 31.6 Flame retardant material))
- Work planes: Epoxy resin molding (32mm thickness)
- Sash: Transparent strengthened glass (5mm-thick) Balance weights method with sash stopper mechanism
- Supply water plug: Remote control method (polyester resin baking coating)
- Lighting devices: Using fluorescent lamps, with switch
-
- Surface speed (m/s) 400mm opening: 0.5
- Air volume (m3/min): 12
- Connection port (φmm): 200
- Duct diameter (φmm): 200
-
- Format: No.200
- Motor (kW): 0.4
-
- Feed drainage amount: 1
- Fluorescent lamps (volume): 20W x 2
- Outlet AC 100V15A double x 2 pieces included
- With surface speed indicator
- Outer dimension (mm): 1200 x 845/750 x 2250
- Inner dimension (mm): 950 x 605 x 1200
- Weight (kg): 305
- Model number: ASF-1200
- *Transportation cost, carrying cost, installation cost, assembly cost, etc. are required separately. Please contact with us. *Exhaust fan delay timer can be installed upon your request (sold separately).
