Spec

• main body material: Hard PVC (vinyl chloride Plastic)
• Sash: 4 mm Thick Transparent PVC (vinyl chloride Plastic) Balance Weight formula
• Lighting: 15 W × 1 lamp 50 / 60Hz switch
• Service outlet: AC100V 15 A Double (With drip-proof Plate)
• power cord: 2.5 m grounded 2P plug OA adapter
• air volume: about 6 m ^ 3 / min (Door 1/3 open, face speed: 0.5 m/s, no load)
• Exhaust fan: Cirocco fan AC100V 0.2 kW made of PVC (vinyl chloride Plastic)
• Fan performance (50 / 60Hz): maximum air flow / 8/10 m3/min, maximum static pressure / 100/150 Pa
• Exhaust fan operating volume: about 65 dB
• Exhaust port: φ 150 mm
• Water supply connection port: 13 A socket
• Wastewater connection port: 20 A socket
• Sink size: 150 x 260 x 80 mm
• Size (mm): 900 x 685/650 x 1850 (excluding fans)
• Fan: Yes
• Water supply / drainage:
• Model number: Z9P-TS8
• * Shipping, carrying, installation and assembly costs are required separately. Please contact us
• * Please contact your facility group for an application for local exhaust equipment
• <

  > AS ONE Corporation Facilities Group ■ TEL : 0120-500-558 ■ Fax : 0120-500-483 ■ Email :
  ■ TEL Reception Time / 9 : 00 to 5 : 30 (Excluding soil, days and holidays)
