61-8305-19 ［Discontinued］Concrete Curing Pack MR204C1
Product Description
Product Model: 61-8305-19Product Brand: CHINO CORPORATI […]
Contact Us
Product Details
Product Model: 61-8305-19
Product Brand: CHINO CORPORATION
Features
- Battery-driven recording makes installation and collection easier than using a recorder.
- The thermocouple sensor can be ***d by cutting the part buried in concrete and reworking the tip of the rest, and the running cost is low.
- A relay connector is ***d together to prevent water droplets from entering due to capillary action.
- With the included cold concrete temperature management support software, "cold concrete temperature management record table" can be easily prepared.
- Curing temperature control in concrete placing construction site.
- *The sensor must be prepared by the customer (recomm***ed: VT3 or VT6 for vinyl coated thermocouple T)
Spec
- Power: 4 AA batteries or AC power adapter
- Power: 4 AA batteries or AC power adapter
- Input point (point): 4
- Input type: Thermocouple K, E, J, T, DC voltage 0~5 V DC, DC current 0~20 mA DC
- Number of recorded data: 10,000 data/channel in Log mode, 5500/channel in Tag mode (when 4 channels are ***d for both)
- Battery life (hours): Approx. 500
- Mass (g): 1660
- Material and Finish: Handy Logger Body/Nylon ABS (Antibacterial Specification), Dedicated Case/PP (Polypropylene)
- Set Contents and Accessories: Handy Logger (Internal Memory Specification), Mounting Holder and Screw Washer, Body Protective Cover (Vinyl Case), 4 AA Alkaline Batteries, AC Adapter, Battery Replacement Adapter, USB Communication Cable, Software CD-ROM, Relay Cable T (MR9406 T) 4 Pieces, Concrete Curing Case, Instruction Manual, Quick Manual
- Securities Code: 722-0278
- There is a separate delivery fee for Hokkaido, Okinawa and remote islands.
