61-4672-55 ［Discontinued］Digital Multimeter AD-5526 AD-5526
Product Description
Product Model: 61-4672-55Product Brand: A&D Feature […]
Contact Us
Product Details
Product Model: 61-4672-55
Product Brand: A&D
Features
- Digital multimeter.
- 1999 count display.
- It can be ***d in a wide range of applications from field measurements such as maintenance to crafts and hobbies.
- With diode test function, battery check function and square wave output function.
Spec
- DC voltage: 200m/2000m/20/200/300V *±(2.5%rdg + 2d) *Full accuracy is displayed
- AC voltage: 200/300V *±(2.5%rdg + 15d) *Full accuracy is displayed
- DC current: 2000μ/20m/200mA *±(2.5%rdg + 10d) *Full accuracy is displayed
- Resistance: 200/2000/20k/200k/2000kΩ *±(2.5%rdg + 5d) *Full accuracy is displayed
- Power supply: LRV08 alkaline cell (12VDC) 1 piece (compatible with 23A, A23, MN21 alkaline cells)
- Accessories: Instruction manual, Cell (for monitor) (**test lead) **test lead cable is directly connected to the body. Removal and installation of the body are not available.
