3-1148-01 ［Discontinued］Desktop Clean Bench Vertical Airflow 840 x 600 x 900 ICBT-840
model:
3-1148-01
category:
gasmonitors
Product Description
Product Model: 3-1148-01 Features A tabletop type for * […]
Contact Us
Product Details
Product Model: 3-1148-01
Features
- A tabletop type for *** on a laboratory or work table.
- A vertical airflow type in which clean air flows perp***icular to the work plane from the top.
- It has 5 levels of air volume adjustment function, so you can quickly clean and operate according to the situation such as energy saving mode.
Spec
- Exterior: Steel plate, melamine baking coating finish
- Work planes: Stainless steel (SUS304) HL finish
- Front door: 4mm-thick Transparent strengthened glass, with Automatic balancing stop mechanism
- Cleanliness: ISO 5 (class 100)
- Dust collection effect: At 0.3μm particles 99.99% or more
- Service outlet: 100V 5A x 1
- Accessories: PAO Nozzle
- Outer dimension (mm): 840 x 600 x 900
- Work area dimensions (mm): 660 x 510 x 580
- Front door upon full opening height: Approximately 150mm
- Front door maximum open dimensions: Approximately 530mm
- Main filter: Thin HEPA filter:
- Pre-filter: Modal acrylic polyester filter
- The number of main filter: 1 sheets
- The number of pre-filter: 1 sheets
- Blow-off wind speed: 0.45m/s
- Air volume: Approx 2 - 6m3/min
- Power supply: AC100V single phase (50/60Hz)
- Power consumption: Approximately 100VA
- Lighting: 20 W x 1 volume
- Weight: Approx 50kg
- Model number: ICBT-840
- *Transportation cost, carrying cost, installation cost, assembly cost, etc. are required separately. Please contact with us. *Contact us for Horizontal airflow form, Vertical airflow form with air curtain, Air curtain circulation form.
