61-4374-90 ［Discontinued］Laser Light Source 3663
Product Description
Product Model: 61-4374-90Product Brand: HIOKI E. E. COR […]
Contact Us
Product Details
Product Model: 61-4374-90
Product Brand: HIOKI E. E. CORPORATION
Features
- Handy-Type Laser Light Source Available in the Field
- Switching between Continuous Light (CW) and Modulated Light
Spec
- Size: 76W x 159H x 35Dmm (including cap)
- Weight: 180g (excluding battery)
- Basic specification: Accuracy warranty period of 1 year, Post-adjustment accuracy warranty period of 1 year
- Light emitting element: Semiconductive laser diode
- Output wavelength : 1310 ± 20nm
- Output mode: CW (continuous light), 270Hz/1kHz/2kHz (modulated light)
- Spectral width: 5nm or less
- Output level: -6 ± 2dBm (at 23℃ ± 5℃)
- Output stability: Within ±0.1dB (for 5 minutes at constant temperature within 23℃ ± 5℃)
- Applicable fiber: Single-mode fiber
- Output connector: FC, SC (using optional connector adapter)
- Conformed standards: IEC60825-1, EN60825-1, Class 1 laser
- Power supply: AA alkaline dry cell (LR6) x 2, 0.6VAmax.
- Continuous *** time: 36h (at CW continuous output)
- Accessories: Carrying case x 1, AA alkaline dry cell (LR6) x 2, Strap x 1, Instruction manual x 1
- *It is unavailable to connect to the optical fiber cable by using only body. for connecting, Select an optional connector adapter and purchase it.
- 3663
