63-4775-62 Yamaichi 0.5mm Pitch 48 Way SMT QFP Test Sockets IC51-0484-806
Product Description
Product Model: 63-4775-62Product Brand: Yamaichi Featur […]
Contact Us
Product Details
Product Model: 63-4775-62
Product Brand: Yamaichi
Features
- QFP Test Sockets - Clamshell. Clamshell test sockets for QFP's Spring loaded hinged lid latches to retain ICs Easy, repeatable access for test purposes High reliability, durability and temperature range Range supports a variety of pitches Body material Glass Filled PES; Glass Filled PEI Contact material Beryllium Copper Contact plating Gold Insulation Resistance 1000 MΩ (At 500 Vdc) Contact resistance 30mΩ (at 10mA) Operating temperature -55°C to 170°C Durability 10000 insertions
Spec
- Quantity：1piece
- Package Type : QFP
- G***er : Female
- Number of Contacts : 48
- Pitch : 0.5mm
- Body Orientation : Straight
- Contact Material : Beryllium Copper
- Contact Plating : Gold over Nickel
- Socket Mounting Type : Surface Mount
- Termination Method : Solder
- Housing Material : PEI, PES, PSU
- CODE No.:372-3403
