61-0173-70 ［Discontinued］Ultrasonic Air Level Meter HAL420
Product Description
Product Model: 61-0173-70Product Brand: Honda Electroni […]
Contact Us
Product Details
Product Model: 61-0173-70
Product Brand: Honda Electronics Co., Ltd.
Features
- Installation, wiring, and operation costs can be reduced by adopting a two-wire system.
- The body is fully chemical resistant resin (PP).
- High resolution of 1mm for both display resolution and internal resolution.
- Compact and lightweight body integrating sensor part and control part.
- Main applications and examples of *** Liquid level control of tanks, etc. Management of treated water levels in sewer pipes. Measurement of water levels in lakes, swamps, and rivers.
Spec
- Number of channels: 1
- Frequency: 50kHz
- Measurement target: Liquid
- Distance measurement range: 0.3 - 6.5m
- Resolution: Measurement: 1mm: Display: 1mm
- Accuracy: ±0.25%F.S. (±1.63cm)
- Data update cycle: 1 second
- Sensor oriented angle (half of full angle of sound pressure): 14°
- Power supply: Voltage: DC16 - 32V: Power consumption: 0.64W
- Display: 4 digits LCD
- Output: 4 - 20mA current output: Resolution: 12bit (maximum load resistance 500Ω: for 24V: 2-wire system)
- Ambient temperature range: -20 - 60℃
- Material: PP (Polypropylene)
- Structure: IP65 equivalent (when lid is opened: IP20 equivalent)
- Outer dimensions: φ93 x 110mm
- Distribution cable length: 10m
- Mass: 350g
- Mounting screw: G2 (PF2)
