61-0107-20 ［Discontinued］Saveris H2E Thermistor Humidity Sensor 5726192
Product Description
Product Model: 61-0107-20Product Brand: Testo K. K. Fea […]
Contact Us
Product Details
Product Model: 61-0107-20
Product Brand: Testo K. K.
Features
- Ethernet probes can be ***d with existing LAN lines. Compared to wireless probe connections, Ethernet connections provide a longer range from the probe to the Saveris base.
- All Ethernet probes have a display.
Spec
- Probe type: NTC, Humidity sensor
- Body measurement range: NTC/-20℃ to +70℃, Humidity sensor/0 - 100%rh (non condensing)
- Body accuracy: NTC/±0.5℃, Humidity sensor/±2%rh (up to 90%rh), ±3%rh (from 90%rh)
- Resolution: NTC/0.1℃, Humidity sensor/0.1%rh/0.1℃td
- Connection: Probe setting service interface (mini-DIN)
- Outer dimensions: 85 x 100 x 38 mm (excluding projections)
- Mass: 230g
- Power (required): 6.3VDC power supply unit, 24VAC/DC power substitute available (screw terminal board connection), PoE feeding
- Buffer power: Lithium ion rechargeable battery
- Protection grade: IP54
- Used temperature: -20 to +60℃
- Power consumption: PoE class 0 (typically 3W or less)
- Display (option): LCD, 2 lines, Displaying icons of 7 items
