61-0172-77 Ultrasonic Oscillator WDX-1200-I
Product Description
Product Model: 61-0172-77Product Brand: Honda Electroni […]
Contact Us
Product Details
Product Model: 61-0172-77
Product Brand: Honda Electronics Co., Ltd.
Features
- The unique Dynashock Modulation (DM) method enabled by Full Digital provides optimal cleaning for applications ranging from soft cleaning to hard cleaning.
- DM (short for DYNASHOCK MODULATION) is an oscillation system that simultaneously oscillates two frequencies from the same oscillator while the total output power remains constant.
- The auto-tuning function eliminates the need to adjust the oscillator when replacing the oscillator unit.
- The front panel display enables output power management.
- When an error occurs, an error message indicating the ca*** of the error is displayed so that prompt action can be taken.
Spec
- Oscillation method: DM oscillation system (0 - 100%) + sweep oscillation
- Rated output: 1200W
- Oscillation frequency: 28kHz, 75kHz
- Power supply: AC200 - 240V ±10% single phase 50/60Hz 2400VA
- Outer dimensions: 330 (W) x 462 (D) x 148 (H) mm
- Mass: 12kg
