61-0103-93 ［Discontinued］testo526-2 Differential Pressure Indicator 5605281
Product Description
Product Model: 61-0103-93Product Brand: Testo K. K. Fea […]
Contact Us
Product Details
Product Model: 61-0103-93
Product Brand: Testo K. K.
Features
- High speed measurement of 25 times per second (We recomm*** that you *** this product in combination with dedicated software.)
- Pressure probes with various measurement ranges can be connected according to the application - differential pressure probe up to -2,000hpa - absolute pressure probe up to -2,000hpa - relative pressure probe up to -400 bar - various temperature probes and current measurement probes can also be connected.
- Can measure wind speed using a pitot tube (testo521 only)
- Memory capacity: approx. 25,000 data
- Data can be printed out on site (printer sold separately).
- Dedicated software can be ***d to manage and analyze data and perform online measurements.
Spec
- Measurement range: 0 - 2,000hPa
- Overload: 3,000hPa
- Static pressure: 2,000hPa
- Accuracy ±1 digit: 1hPa
- Resolution: 0.1hPa
- Sensor type: Piezoelectric resistance method pressure sensor
- Operation temperature: 0 to +50℃
- Battery type: 9V block type cell (6LR61)
- Battery life: Alkaline dry cell/approximately 30 hours, Manganese dry cell/approximately 18 hours, Nickel hydrogen rechargeable battery/approximately 10 hours
- Power supply: Dry battery, Rechargeable battery, AC adapter (DC12V)
- PC connections: RS232 interface
- Display: LCD
- Housing: ABS resin
- Display update interval: 2 times per second (at standard measurement), 4 times per second (at high-speed measurement)
- Connection hose: Inner diameter φ4mm, Outer diameter φ6mm
- Memory capacity: Approximately 25,000 data
- Outer dimensions: 219 x 68 x 50mm
- Mass 300g
