61-9734-79 ［Discontinued］Pocketable Combustible Gas Monitor Catalytic Combustion Type FPA-5000E
Product Description
Product Model: 61-9734-79Product Brand: KITAGAWA, KOMYO […]
Contact Us
Product Details
Product Model: 61-9734-79
Product Brand: KITAGAWA, KOMYO RIKAGAKU KOGYO K. K.
Features
- * Please let us know the address on the certificate.
- Protects workers from gas explosion disasters by acting as personal monitors when flammable gas leaks when working in areas where flammable gas is generated (chemical plants, paint plants, printing plants, etc.).
- 1. EX Explosion-Proof Standard Accepted Product Exia II CT4X (TC No. 17118)
- 2. Small, lightweight, weight 170 g
- 3. Alarm density can be set arbitrarily
- 4. Digital display unit for easy viewing of density display, battery change, sensor abnormality, etc.
- 5. Power supply is AAA alkaline type battery which can be ***d for a long time with low power consumption
- 6. Battery capacity display when power is ON, sensor check is fully automatic
- 7. Peak hold function is installed
- 8. Sensor is not susceptible to downward structure, water and dust
Spec
- Gas sampling method: Diffusion
- Measurement target gas: Atmospheric inflammable gas
- Measurement principle: Catalytic combustion type
- Measurement range: 0 - 100% LEL
- Minimum display digit: 1%LEL
- Indication accuracy: +/-10% LEL or less
- Alarm concentration: 20%LEL
- Alarm method: LED lamp, LCD display, Buzzer
- Explosion-protection: ExiadIICT4X (No. TC17118)
- Response time: 62.5% response, 15 seconds or less
- Major functions: Display lighting, Battery remaining amount display, Automatic calibration
- Power supply: AAA alkaline dry cell 3 piece
- Continuous *** time: Approx 16 hours
- Operating temperature range: - 10 - 40℃ (Humidity: 30 - 85%RH, Non-condensing)
- Dimensions: 105 (W) x 56 (H) x 29 (D) mm (except for the sensor unit)
- Body mass: Approximately 170g (including battery)
- Accessories: Soft case
- Calibration certificate (breakdown: calibration certificate, certificate of test, traceability system diagram)
