61-0003-15 ［Discontinued］Sound Level Meter SL-1320
Product Description
Product Model: 61-0003-15Product Brand: CUSTOM corporat […]
Contact Us
Product Details
Product Model: 61-0003-15
Product Brand: CUSTOM corporation
Features
- MAX (maximum value)/MIN (minimum value) With memory.
- It has MAXHOLD function to display fixed maximum value.
- It has a backlight function.
- Auto power off function is included. (The power is automatically turned off if there is no operation for 20 minutes after the last button operation.).
- Analog output jack included.
Spec
- Measurement range: [A/C manual range] 40 - 70, 60 - 90, 80 - 110, 100 - 130dB, [A Characteristics auto-range] 40 - 130dB, [C Characteristics auto-range] 45 - 130dB
- Resolution: 0.1dB,
- Measurement accuracy: ±2dB (94dB, At 1kHz)
- Frequency range: 31.5Hz - 8kHz
- Used temperature and humidity: 0 to +50℃, 80%RH or less (however, no condensation)
- Storage temperature and humidity: -20 to +50℃, 90%RH or less (however, no condensation)
- Power supply: AAA (1.5V) cell x 4 pieces
- Battery life: About 40 hour (when using alkaline cell)
- Dimensions: W57 x H215 x D30mm
- Weight: Approx 160g
