Features

• These connectors should not be mated or unmated under electrical load. Connectors of the same or different types arranged in a line should be polarised to prevent the possibility of wrong connection. For crimp tooling for the contacts associated with the Han® D inserts see stock no. ; 114-7706 114-7706 or ; 313-6607 313-6607. Han Quintax® Module. Each Qunitax® cylindrical insert accommodates 4 crimp contacts similar to those fitted to the Han® D inserts (See stock no. ; 156-7267 156-7267 ) Two Han Quintax® cylindrical inserts can be fitted to each Quintax® module Two Quintax® modules may be fitted to a 4-module frame (stock no. ; 329-9809 329-9809 or ; 329-9815 329-9815 ) which in turn can be fitted to a Harting Series ‘10A ‘ housing (e.g. Stock no. ; 114-8052 114-8052 - See RS Range 2) Suitable for screened cable with outer diameter of 3-6mm or 6-9.5mm Ideal for transmitting very sensitive signals (BUS signals) Mating cycles ≥500
