61-0002-68-24 [Discontinued]Digital multimeter JCSS calibration CDM-6000
Product Description
Product Model: 61-0002-68-24Product Brand: CUSTOM corpo […]
Contact Us
Product Details
Product Model: 61-0002-68-24
Product Brand: CUSTOM corporation
Features
- A multimeter that covers a wide range.
- DC current (μA) measurement is also supported.
Spec
- < AC Voltage >
- Range: 600 mV, 6 V, 60 V, 600 V, 750 V
- Resolution: 0.1 mV, 0.001 V, 0.01 V, 0.1 V, 1 V
- Accuracy: ± (0.9%rdt+5dgt), 6 V to 750 V, 50 Hz to 60 Hz
- DC Voltage
- Range: 600 mV, 6 V, 60 V, 600 V, 1000 V
- Resolution: 0.1 mV, 0.001 V, 0.01 V, 0.1 V, 1 V
- Accuracy: ± (0.5%rdt+2dgt)
- DC Current
- Range: 600 μA, 6000 μA Resolution: 0.1 μA, 1 μA
- Accuracy: ± (1.0%rdt+2dgt)
- < Resistance >
- Range: 600 Ω, 6 kΩ, 60 kΩ, 600 kΩ, 6 MΩ, 60 MΩ
- Resolution: 0.1 Ω, 0.001k1Ω, 0.01 kΩ, 0.1 kΩ, 0.001 MΩ, 0.01 MΩ
- Accuracy: ± (0.7%rdt+2dgt)/600 Ω~600 kΩ
- working principle: double integration method
- Display: 3.5 digit LCD display, up to 6000 counts
- Range: Auto or Manual
- Over display: "OL" display
- Polarity display: Automatic switching, "-" only displayed
- Sample: 2 times/second
- Operating temperature and humidity: +10~+50°C, 80%RH or less (However, there shall be no condensation.)
- Storage temperature and humidity: -20~+60°C, 80%RH or less (However, there shall be no condensation.)
- Power: 2 AAA (1.5 V) batteries
- Dimensions and weight: W82 x H164 x D44mm, about 365 g
- Accessories: Test Lead, Holster Case, Alligator Clip
- Calibration Items: DC Voltage, DC Current, DC Resistance, AC Voltage 50 Hz, AC Current 50 Hz
