Spec

• Model number: ADL12
• Maximum external dimensions (mm): 167 x 91 x 35.8
• measurement item: Temperature, Voltage and Humidity
• Thermo-thermocouple measurements: B, R, S, N, K, E, J, T (Select one)
• measurement temperature range: 200 to 1370 °C (When using K class thermocouple)
• Voltage measurement: 100, 500 mV, 1.5, 10, 50 V
• Measure measurement: ±0.05% of rdg + 1.0 °C (K: 100 to 1370 °C at 25 °C)
• Voltage measurement accuracy: ±0.1% of F.S.
• Humidity Measurement: 0 to 100 %RH
• Input channel: Analog/12 CH for humidity measurement + 5V-OUT/1CH
• Input terminal shape: Screw terminal M3/* 1 M3.5 (Outside dimensions 6.2mm or less/inner diameter 3.2mm or higher)
• Voltage measurement: 100, 500 V, 15, 50, 10, 50
• Voltage measurement accuracy: ±0.1% of F.S.
• Humidity Measurement: 0 to 100 %RH
• Humidity measurement accuracy: ±5 %RH (TYP) (10 to 95 %RH at 23 °C)
• Input channel: Analog/12 CH for humidity measurement + 5V-OUT/1CH
• Input terminal shape: Screw terminal M3/* 3.5 (Outside 6mm or less/inner diameter 3.2mm or higher)
• Sampling period: 5 seconds, 10 seconds, 30 seconds, 60 seconds, 5 minutes, 10 minutes, 30 minutes, 60 minutes
• PCI/F: USB 2.0 (full speed) mini B type
• Card slots: 1 slot, no SDHC, approx. 512 MB/approx. 1 GB/2 GB
• Memory: PC storage using SD card applications
• recording format: saving from CSV recording start to 1 file
• Number of records: 5 million (2 GB)
• Accessories: Simplified manual, AC adapter and USB cable approx. 1M (For power supply and communication)
• * There is no attached wire material on the body. Prepare for your application.
• * We have a demo machine.
•

• * Supported OS: Windows (R) 7/8/8.1/10
• * Function: Real-time measurement on an application, start/*** of recording, data saving, body configuration, SD card data reading, display
• * Display method: Graph display (Cascade feature), list display, maximum, minimum, average, and comparison values for measurement data
• Download
• * Supported OS: Windows ® 7/8/8.1/10 (32 64 bit)
