3-3922-11 Dry Scrubber Unit (indoor installation type) air volume : 12 (m3/min) UC-12
Product Description
Product Model: 3-3922-11Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3922-11
Product Brand: AS ONE Corporation
Features
- A dry scrubber for indoor installation.
- Adsorption treatment with exhaust gas generated from the hood is carried out in the adsorption tower section of the unit.
- Suitable for the treatment of organic gases and water-insoluble gases.
Spec
- Model number: UC -12
- external dimension (mm): 700 x 830 x 2250
- Weight (About kg): 150
- air volume (m3/min): 12
- Duct Connector: 200 A (inlet and outlet)
- Diameter of required duct: Φ 200 mm
- Activated Carbon Cassette: 24 pieces
- Activated charcoal Weight: 19 kg
- Static pressure in the column: 490 Pa
- Exterior: Steel (powder coating finish)
- Adsorption tower: PVC (Plastic vinyl chloride ), upper and lower 2 stages
- Attached activated carbon: Unicell activated carbon cartridge 4GM for neutral gas
- Pre-filter: nonwoven fabric Coarse Dust Filter (With aluminium frames)
- Accumulated timer: Includes an accumulated timer for reducing the amount of activated carbon replacement
- Sampling port: with gas sampling port (IN side x 1 location, OUT side x 1 location)
- *Contact us if you are using an activated carbon cartridge for acid gas (SX) or basic gas (AX).
- *Shipping, carrying-in, installation, assembly, etc. are required separately. Please contact us.
- *Exhaust fan is not included.
