3-3917-21 Fume Hood (High Line/Low Work Surface Type) Deep 1200 x 980 x 2350 mm ABDCL-1200
Product Description
Product Model: 3-3917-21Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3917-21
Product Brand: AS ONE Corporation
Features
- The work surface height is 200 mm lower and the internal effective height is 300 mm higher, making it suitable for *** with tall equipment and instruments.
- The height of the front sash is also larger than the normal size at 950 mm, making it easy to observe the inside of the hood.
- For Acid/Alkali
- For Organic
Spec
- specifications: deep
- External Dimensions (mm): 1200 x 980 x 2350
- Inner Dimensions (mm): 950 x 755 x 1500
- Weight (approx. kg): 345
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
- Lifting Sash: Tempered Glass (5 mm Thickness) Balance Weight Type with Opening Limiting Key (Height 400 mm) Double Sash
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- [Exhaust]
- Air volume (m3/min): 13
- Duct Connection Port: 200 A
- Required Duct Diameter (φmm): 200
- [Ancillary Facilities]
- Fluorescent Lamp (Pieces): 20 W x 2 Lamps Equivalent
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
