3-3912-21 Fume Hood (Low Ceiling Type) Standard 1200 x 830 x 2100 mm ABSM-1200
Product Description
Product Model: 3-3912-21Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3912-21
Product Brand: AS ONE Corporation
Features
- Since the total height of the device is 2100 mm, it can be installed in places with low ceilings.
- Suitable for installation in special rooms with low ceilings, such as clean booths and environmental test rooms, or in booths.
- For Acid/Alkali
- For Organic
Spec
- Specifications: Standard
- External Dimensions (mm): 1200 x 830 x 2100
- Inner Dimensions (mm): 950 x 605 x 1100
- Weight (approx. kg): 260
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Chemical-Resistant/Heat-Resistant Board (Flame Retardant/Phenolic Resin Laminated Board), Work Surface/Epoxy Resin Top Plate Integrally Molded Product (32 mm Thickness)
- Lifting Sash: Tempered Glass (5 mm Thickness), with Balance Weight Type Opening Limiting Key (Height 400 mm), Handle/ABS Resin
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
