3-3902-21 Fume Hood (Interior PVC Type) Deep 1200 x 980 x 2250 mm ABDPN-1200
Product Description
Product Model: 3-3902-21Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3902-21
Product Brand: AS ONE Corporation
Features
- Hood interior, work surface, exhaust flow straightening plate and sash are all made of PVC, and it is a type specialized in chemical resistance to acid and alkali chemicals.
- For Acid/Alkali
Spec
- specifications: deep
- External Dimensions (mm): 1200 x 980 x 2250
- Inner Dimensions (mm): 950 x 755 x 1200
- Weight (approx. kg): 325
- Control wind speed: 0.5 m/s (Opening height of sash at work: 400 mm)
- Material: Exterior/Steel (Powder Coating Finish), Interior/Work Surface/PVC (Vinyl Chloride Resin)
- Lifting Sash: PVC (Vinyl Chloride Resin) (5 mm Thickness) Balance Weight Type with Opening Limiting Key (Height 400 mm), Handle/ABS Resin
- Hydrant: Chemical-Resistant Coating Remote Control Type/1 Location Water Supply Connection Opening G1/2 (Female Screw Stopper)
- Drain Port: Drain Connection Port 25 A with Recessed Resin Sink and Drain Trap
- Outlets: 2 (100 VAC 15 A with 2 connected grounding)
- lighting: LED fluorescent
- Operation Switch: Touch Panel Lighting/Fan
- safety features: exhaust airflow display
- Exhaust Connection: PVC (Vinyl Chloride Resin) Volume Damper Phase Flanged
- Power connection: Terminal block with electrical box
- [Exhaust]
- Air volume (m3/min): 13
- Duct Connection Port: 200 A
- Required Duct Diameter (φmm): 200
- [Ancillary Facilities]
- Fluorescent Lamp (Pieces): 20 W x 2 Lamps Equivalent
- *Shipping, delivery, installation and assembly costs are required separately. Please contact us.
- *Exhaust fan is not included. Please contact us.
