Spec

• Size (mm): 167 x 91 x 35.8
• Specifications (Body)
• Thermocouple measurement: B, R, S, N, K, E, J, T (choose one)
• Measuring temperature range: -200 to + 1370 degrees C (when using a K thermocouple)
• Temperature measurement accuracy: +/- 0.05% of rdg + 1.0 degrees C (K: -100 to + 1370 degrees C at 25 degrees C)
• DC Voltage Measurement: 100, 500 mV, 1, 5, 10, 50 V
• DC voltage measurement accuracy: +/- 0.1% of F.S.
• Humidity reading: 0 ~ 100% RH
• Humidity measurement accuracy: +/- 5% RH (TYP) (10 ~ 95% RH at 23 degrees C)
• Input channels: Analog/12 CH, + 5 V-OUT/1 CH for humidity measurement
• Input terminal shape: Screw type terminal M3/* M 3.5 (outer dimension 6.2 mm or less/inner diameter 3.2 mm or more)
• Sampling period: 5, 10, 30, 60 sec, 5, 10, 30, 60 min
• PC I/F: USB 2.0 (Full Speed) Mini B Type
• Card slot: 1 slot, SDHC compatible, available memory: 64 GB to 32 GB (not SDXC)
• Memory: PC storage via SD card application
• Recording format: Save in one file from the start of CSV recording
• Records: 5 million (for 2 GB)
• Accessories: simplified instruction manual, AC adapter, USB cable approx. 1M (for power supply and communication)
• Specifications (Applications)
• Operating System: Windows ® 8/8. 1/10 (32/64 bit)
• Functions: Real-time measurement on application, recording start/stop, data storage, device settings, reading and displaying SD card data
• Display method: Graph display (with overlay function), list display, maximum/minimum/average/comparison value display function of measured data
• *Thermoelectric equivalent connecting wire is not included in the body. Prepare according to your int***ed ***.
• *We have rental machines available.
• < a href="https://axel.as-1.co.jp/images/pdf/pb/3-6823-31/adl12_controller_v121.zip" rel="noopener nofollow" target="_blank" > Download the dedicated application (v 121) here < /a >
• Operating System: Windows ® 7/8/8.1/10 (32/64 bit)
• < a href="https://axel.as-1.co.jp/images/pdf/pb/3-6823-01/ADL12_Driver_V1.0.zip"rel="nofollow" > If you need a driver for your USB connection, click here < /a >
• *Express proofreading is a service that delivers products with proof of proofreading at a faster delivery time than usual.
