2-568-01 ［Discontinued］Handheld LCR Meter LCR-915
Product Description
Product Model: 2-568-01Product Brand: GW INSTEK (TEXIO […]
Contact Us
Product Details
Product Model: 2-568-01
Product Brand: GW INSTEK (TEXIO TECHNOLOGY CORPORATION)
Features
- Auto LCR mode automatically identifies specific L, C, or R and parameters for both parallel and series circuits while measuring the device being measured.
- The test frequency can be selected to elicit the characteristics of the object to be measured.
Spec
- Basic accuracy: 0.2％
- Display: 2000/20000 counts (selectable)
- Size: 95 x 52 x 207mm
- Weight: Approx 630g
- Function: Auto LCR function, Auto range function, Parallel/serial test mode (selectable), Maximum/minimum mode (LCR-916 only)
- Power supply: AA Dry cell x 4 volume (included for test), USB bus power, AC adapter
- Test frequency (Hz): 100/120/1k/10k
- Item to be measured: L, C, R (AC/DC), D, Q, ESR, θ
- Model number: LCR-915
