1-9499-31 ［Discontinued］Low Concentration Oxygen Concentrator Lead Length Approx. 1.7 m JKO-O2LJD3-K
Product Description
Product Model: 1-9499-31Product Brand: ICHINEN JIKCO Lt […]
Contact Us
Product Details
Product Model: 1-9499-31
Product Brand: ICHINEN JIKCO Ltd.
Features
- It ***s a sensor with a fast response speed to measure residual oxygen concentration, which is a low concentration area.
- The sensor is M16 P1 threaded and can be connected directly to the device or an in-line jig (sold separately) can be ***d to measure the oxygen concentration in the piping (line).
Spec
- Measuring range (%): 0 ~ 25.00
- Resolution (%): 0.01
- Number of pieces: 1
- Detection principle: Galvani battery type
- Response time: About 5 seconds (90% response), about 40 seconds (99.5% response)
- Alarm: 2 levels (optional), electronic buzzer sound (80 dB), red LED flashing x 2
- Alarm Output: Relay Non-Voltage 1 c Contact, Maximum Load Capacity/300 mA/30 VDC
- Analog output: 4 ~ 20 mA (FS)/dedicated harness (included)
- Power supply: 4 AA alkaline batteries (included for testing) or AC adapter (included)
- Battery life: 2000 hours
- Size: 82 x 38 x 145 mm
- Weight: body/190 g, sensor part/140 g
- Lead wire length: about 1.7 m
- Wall bracket included
- Operating pressure range: atmospheric pressure +/- 10% * Measure gas pressure at a constant level.
