3-7758-01 ［Discontinued］Chemical Storage Shelf (With Air Cleaning Function) 796 x 470 x 1752mm NS800
model:
3-7758-01
category:
gasmonitors
Product Description
Product Model: 3-7758-01 Features With air cleaning fun […]
Contact Us
Product Details
Product Model: 3-7758-01
Features
- With air cleaning function.
- Since it is a ductless type, it can be installed anywhere.
- By selecting the same type of filter at the top and bottom, you can filter the target chemical substances and fine particles more reliably.
- The monitor information of the sensor is displayed on the LCD panel and can be controlled.
- It detects the saturation state of the filter and emits a light and sound warning when the filtration efficiency decreases.
Spec
- Model number: NS 800
- External dimensions (mm): 525 x 2362 x 800
- Inner dimensions (mm): 470 x 1752 x 796
- Reagent bottle number of storage: 500 ml x 160 bottles
- Exhaust air volume: 240 m3/h
- Ventilation rate: 410 times/h
- Power supply: AC100V 50/60 Hz 30 W
- Weight: 120 kg
- Material : Main unit/galvanizing Steel , Door/PMMA (acrylic)
- Shelf board Load tolerance : 100 kg (equal load)
- Activated carbon filter: Cleared ASTM standards in the United States and AFNOR NFX -211 15 -2009 in France
-
- *General activated carbon (TY) filter x 2 sets
- *shelf board x 4 pieces
- *Waste liquid receiver (bottom of the body) x 2 pieces
- *Chemical absorption mat x 1 piece
- *Transportation, delivery, installation, assembly, etc. are required separately. Please contact us.
