1-6269-21 ［Discontinued］Gas Monitor GX-2009 TypeA 4 Components Measurable GX-2009TYPEA
Product Description
Product Model: 1-6269-21Product Brand: RIKEN KEIKI Co., […]
Contact Us
Product Details
Product Model: 1-6269-21
Product Brand: RIKEN KEIKI Co., Ltd.
Features
- Oxygen, combustible gas, carbon monoxide, and hydrogen sulfide are able to be measured and displayed simultaneously.
- Loud alarm that is over 95dB（A）, alarm indicator lamp, and vibrator easily warn you of danger even in noisy environments.
Spec
- Model number: GX-2009TYPE A
- Detection gas: Oxygen (O2), combustible gas (HC), carbon monoxide (CO), hydrogen sulfide (H2S)
- Detection principle: Oxygen (O2)/diaphragm galvanic battery type, Combustible gas (HC)/catalytic combustion type, Carbon monoxide (CO)/controlled potential electrolysis type, Hydrogen sulfide (H2S)/controlled-potential electrolysis type,
- Detection range (reference range): Oxygen (O2)/0 - 25vol%, Combustible gas (HC)/0 - 100% LEL, Carbon monoxide (CO)/0 - 150ppm, Hydrogen sulfide (H2S)/0 - 30.0ppm
- Alarm settings: Oxygen (O2)/L alarm: 18.0vol%, H alarm: 25.0vol%, OVER: 40.0vol%, Combustible gas (HC)/1st: 10% LEL, 2nd: 50% LEL, OVER: 100% LEL, Carbon monoxide (CO)/1st: 25ppm, 2nd: 50ppm, TWA: 25ppm, STEL: 200ppm, OVER: 500ppm, Hydrogen sulfide (H2S)/1st: 1ppm, 2nd: 10ppm, TWA: 1ppm, STEL: 5ppm, OVER: 30ppm
- Alarm display: At gas alarm: Lamp blinks, Intermittent buzzer, Gas density value flashes, Vibration, At failure alarm: Lamp blinks, Intermittent buzzer, Failure contents display
- Gas sampling: Diffusion
- Explosion-protection: Intrinsically safe structure Exia CT4 certificate number is TC18582
- Power supply: Ni - MH cell (allowable continuous *** time 18 hours or more)
- Size, weight: Approx 76 x 26 x 69mm, approx 130g (body only)
- Accessories: Hand strap, Charger, Belt fixing clip
- Measurement type: 4 components
- Measurement gas: O2, LEL, H2S, CO
