1-3710-03 ［Discontinued］Mass Flow Meter MCF0250ARND010000
Product Description
Product Model: 1-3710-03Product Brand: Azbil Corporatio […]
Contact Us
Product Details
Product Model: 1-3710-03
Product Brand: Azbil Corporation
Features
- It can be ***d for compressor air flow control and also for air leakage monitoring.
- Since the display section rotates more than 90° left and 180° right, one unit can handle all flows.
- Equipped with backflow detection and normal backflow accumulation function, it can also handle loop piping.
Spec
- Model number: MCF0250ARND010000
- Maximum flow rate (L/min): 3000
- Connection port size: Rc1B
- Conform fluid: Air and nitrogen
- Accuracy: +/- 3% FS
- Used pressure: 1.0MPa (MAX)
- Pressure resistance: 1.5MPa
- Display: 7 segments LED 5 digits, Instant/integration flow rate
- Function: Integration pulse/alarm output, instant flow rate switch up or down limit, etc.
- Power supply: DC24V
- Size: 90 x 47 x 79.8mm
- Weight: 500g
- Dustproof, waterproof: IP65
