4-3403-01 ［Discontinued］Fume Hood (model incorporating organic solvent refiner) 1200 x 830 x 2250 mm 2 solvent ABSI-1200T-GC2S
Product Description
Product Model: 4-3403-01Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-3403-01
Product Brand: AS ONE Corporation
Features
- This is a new fume hood equipped with an organic solvent purifier.
- There is a key on the broken door.
- It can dehydrate about 400 L with a special grade solvent.
- It is possible to incorporate a trestle capable of handling 2 to 5 solvents.
- A total of 35 solvents can be purified (please contact us for details).
- Organic Solvent Refiner (GlassConyour) Flow Description
- (1) Gas (99.999% nitrogen gas or argon gas) * High-purity inert gas is introduced into the keg.
- (2) Keg (20 L or anhydrous canister can) * The pressurized solvent moves from the keg to the column.
- (3) Column (After passing through the primary side, the secondary side) Upflow * The catalyst in the column removes water contained in the solvent.
- (4) Replacement work in the flask (simple operation of the valve only) * Replace the oxygen in the flask with inert gas.
- (5) Solvent comes out after water has been removed.
Spec
- External dimensions (mm): 1200 x 830 x 2250
- Internal dimensions (mm): 950 x 605 x 1200
- Number of solvents: 2
- Organic Solvent Purifier Size: GC2S/670 x 400 x 920 mm, GC3S/920 x 400 x 920 mm, GC4S/1170 x 400 x 920 mm, GC5S/1420 x 400 x 920 mm
- Exterior: SPCC (powder coating finish)
- Interior: Chemical and heat resistant board
- Organic Solvent Purifier: Stainless Steel (SUS 304)
- Work surface: Epoxy resin top integral part (32 mm thick)
- Lifting sash: Tempered glass (5 mm thick) with balance-weight aperture restriction key (400 mm high), handle/ABS resin
- Outlet: 100 VAC -15 A with 2 serial grounding
- Lighting: LED Fluorescent
- Operating switch: Touch-panel lighting/fan
- Safety features: Exhaust airflow indication
- Exhaust connection: PVC (Polyvinyl Chloride Resin) volume damper with phase flange
- Power connections: terminal block with electrical box
- (Exhaust)
- Working sash opening height (mm): 400
- Controlled wind speed (m/s): 0.5
- Airflow (m3/min): 13
- Duct connector: 200 A
- Required duct diameter (phi mm): 200
- (Ancillary facilities)
- Plumbing (location): 1
- Fluorescent (light): 20 W x 2 light equivalent
- Outlet (location): 2
- Epoxy Top: 270
- *Shipping, carrying-in, installation and assembly costs are required separately. Please inquire.
- *Exhaust fan is not included. Please inquire.
