4-3312-01 ［Discontinued］Fume Hood (Tabletop, high-line type) 1200 x 750 x 1950 mm standard ASTC-1200
Product Description
Product Model: 4-3312-01Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-3312-01
Product Brand: AS ONE Corporation
Features
- It is installed on a side laboratory table or work table.
- The effective height in the cabinet is 550 mm higher than the tabletop type (AST), so it is suitable for *** with tall equipment and appliances.
Spec
- Specifications: Standard
- External dimensions (mm): 1200 x 750 x 1950
- Internal dimensions (mm): 950 x 525 x 1750
- Weight (approx. kg): 135
- Number of pieces: 1
- Exterior: Steel (powder coating finish)
- Interior: Chemical and heat resistant board (flame retardant, phenolic resin laminate)
- Work surface: not attached
- Lifting sash: Tempered glass (5 mm thick) with balance-weight aperture restriction key (400 mm high), handle/ABS resin
- Hydrant: not included
- Outlet: Not included
- Outlet: 100 VAC -15 A with 2 serial grounding
- Lighting: LED Fluorescent
- Operating switch: Touch-panel lighting/fan
- Safety features: Exhaust airflow indication
- Exhaust connection: PVC (Polyvinyl Chloride Resin) volume damper with phase flange
- Power connections: terminal block with electrical box
- (Exhaust)
- Working sash opening height (mm): 400
- Controlled wind speed (m/s): 0.5
- Airflow (m3/min): 13
- Duct connector: 200 A
- Required duct diameter (phi mm): 200
- (Ancillary facilities)
- Fluorescent (light): 20 W x 2 light equivalent
- Outlet (location): 2
- *Shipping, carrying-in, installation and assembly costs are required separately. Please inquire.
- *Exhaust fan is not included. Please inquire.
