4-1184-15 ［Discontinued］Fume Hood (with built-in HEPA filter) Deep type 1200 x 980 x 2250 mm ABD-1200HP
Product Description
Product Model: 4-1184-15Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-1184-15
Product Brand: AS ONE Corporation
Features
- Fume hood suitable for powder work with HEPA filter attached to the back side of the baffle plate.
- The air volume display function is equipped as standard, and you can check the exhaust condition and work.
- The sash is a left-right sliding type, and the work frontage can be taken off high, so it is suitable for measuring work.
Spec
- Specifications: Deep
- External dimensions (mm): 1200 x 980 x 2250
- Internal dimensions (mm): 950 x 660 x 1200
- Weight (approx. kg): 325
- Exterior: Steel (powder coating finish)
- Interior: Chemical and heat resistant board (flame retardant, phenolic resin laminate)
- Filter: High air volume HEPA filter Prefilter
- Work surface: Epoxy resin top integral part (32 mm thick)
- Sash: Tempered glass (5mm thick) right and left sliding type
- Hydrant: Chemical-resistant paint remote-operated water supply connection port G 1/2 (female screw)
- Outlet: Drain connection with resin embedded sink and drain trap 25 A
- Outlet: 100 VAC -15 A with 2 serial grounding
- Lighting: LED Fluorescent
- Operating switch: Touch-panel lighting/fan
- Safety features: Exhaust airflow indication
- Exhaust connection: PVC (Polyvinyl Chloride Resin) volume damper with phase flange
- Power connections: terminal block with electrical box
- (Exhaust)
- Working sash opening height (mm): 700
- Controlled wind speed (m/s): 1.0
- Airflow (m3/min): 19
- Duct connector: 250 A
- Required duct diameter (phi mm): 250
- (Ancillary facilities)
- Plumbing (location): 1
- Fluorescent (light): 20 W x 2 light equivalent
- Outlet (location): 2
- *Shipping, carrying-in, installation and assembly costs are required separately. Please inquire.
- *Exhaust fan is not included. Please inquire.
