4-1184-01 ［Discontinued］Fume Hood (HEPA filter type) ABS-1200HP
Product Description
Product Model: 4-1184-01Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 4-1184-01
Product Brand: AS ONE Corporation
Features
- A fume hood suitable for powder work with a HEPA filter attached to the back of the baffle plate.
- The air volume display function is equipped as standard, and you can check the exhaust condition and work.
- The work surface is an epoxy top plate with excellent chemical resistance and cost performance.
Spec
- external dimension (mm): 1200 x 830 x 2250
- inner size (mm): 950 x 455 x 1200
- Weight (About kg): 270
- Exterior: Steel (powder coating finish)
- Interior: chemical resistant Heat-Resistant Board (Flame-Retardant material/phenolic laminated sheet or glass fiber mixed polyester)
- Filter: High air volume HEPA filter prefilter
- Work Plane: Epoxy Plastic top board Integral Part (32 mm Atsushi)
- Lifting sash: tempered glass (5 mm Atsushi) with balance weight opening restriction key (400 mm Height), Handle/ABS Plastic
- Hydrant: chemical coating Remote Operated Water Connection G 1/2 (Stop Female thread)
- drain port: Plastic Drainage connector 25 A with a built-in sink and trap
- Outlet: AC100V -15 A2 grounded
- lighting: LED fluorescent lamps
- Operating Switch: Touch Panel Lighting/Fan
- Safety Function: Exhaust Air air volume Display
- Exhaust Connections: PVC (Plastic vinyl chloride ) with Volume Damper Phase Flanged
- power supply connection part: Terminal block with electric box
- exhaust
- Work Sash Opening Height (mm): 400
- Controlled wind speed (m/s): 0.5
- air volume (m3/min): 13
- Duct Connector: 200 A
- Required duct diameter (Φ mm): 200
- Appurtenance: water supply and drainage (place)/1, fluorescent lamps (main)/equivalent to 2 20 W lights, receptacle (place)/2
