1-1112-01 ［Discontinued］Hydrogen Alarm JK-HYD
Product Description
Product Model: 1-1112-01Product Brand: ICHINEN JIKCO Lt […]
Contact Us
Product Details
Product Model: 1-1112-01
Product Brand: ICHINEN JIKCO Ltd.
Features
- Uses a highly sensitive sensor with excellent selectivity and little influence from organic solvents.
- Wall-mounted type with long life, excellent long-term stability, and resistant to vibration and impact.
- Alarm is announced by buzzer and lamp (with external output function).
- It quickly catches small leaks of hydrogen gas.
Spec
- Model number: JK-HYD
- Alarm gas concentration: 500ppm
- Alarm method: 1 stage alarm (red color lamp lighting, intermittent electron sound), Instant type, Automatic return type
- External output signal: 1a non-voltage, Contact output (AC250V/DC30V 5A resistance load in this regard)
- Display: Green lamp/lighting when power is ON, Yellow lamp/flashing during problems (sensor disconnected), Red lamp/lighting during gas alarm (automatic return)
- Power supply: AC100V +/- 10% 50/60Hz, Power plug with preliminary outlet, Cord 2.5m
- Power consumption: 6W
- Weight: Approx 500g
- Retention circuit: Activation prevention circuit during energization (approximately 3 minutes)
- Accessories: Mounting bracket 1 set:
- Size: 80 x 55 x 171mm
