64-1203-18 [Discontinued]Housing 1PP-1-ME-00 43032000
Product Description
Product Model: 64-1203-18Product Brand: ADVANTEC Featur […]
Contact Us
Product Details
Product Model: 64-1203-18
Product Brand: ADVANTEC
Features
- Plastic housing for one piece consisting of head and torso.
- High-purity polypropylene, free of fillers and colorants, rarely elutes from the housing and can be ***d to filter high-purity chemicals and ultrapure water.
- Since the inner surface of the housing is smooth, the retention and adhesion of fine particles and microorganisms are unlikely, and the sanitary property is excellent.
- 1PP type is available for 250 mm filter size type and 500 mm filter size type. You can select models that can support cartridge filter shape codes C, F (flat gasket DOE), TCW type and M, H (222 O-ring SOE).
Spec
- Number of Cartridges: 250 mm x 1 piece
- Applicable Cartridge Filter Shape Code: M, H (222 O-Ring SOE)
- IN/OUT Shape: 3/4 "PTF (3/4" with PT Nipple)
- Dimensions : overall height/340 mm , full width/200 mm
- maximum working pressure: 0.49 MPa (25 °C), 0.19 MPa (60 °C)
- Maximum operating temperature: 60 °C
- material: Head/Polypropylene, Trunk/Polypropylene, O-Ring/Ethylene Propylene, Vent/SUS304 (Push Button Type/Standard), Drain Plug/Polypropylene, 3/4 "PT Nipple/Polypropylene
- Mass (kg): 0.84
- Pressure gauge: None
