64-1030-05 ［Discontinued］Freeze dryer DRW282FA
Product Description
Product Model: 64-1030-05Product Brand: ADVANTEC Featur […]
Contact Us
Product Details
Product Model: 64-1030-05
Product Brand: ADVANTEC
Features
- In the automatic mode operation, the trap cooling temperature and vacuum degree are judged, and the condition that the sample can be installed is informed.
- The timer function is installed, and the accumulated vacuum pump operation time and freeze drying time are displayed.
- The vacuum pump can be built into the main body, so you can *** the installation space effectively.
- The *** of an external power outlet prevents the vacuum pump from automatically returning to operation when the power failure returns, and prevents the melted sample from being blown up and scattered due to the power failure.
Spec
- Trap cooling temperature (°C): -80
- Trap Dehumidification capacity (L/time): 3
- Ambient operating temperature: 5 °C, to 35 °C
- Refrigerator: 500 W x 2 R 404 A/R 23
- Operation Configuration : Auto Mode Operation , Manual Mode Operation
- Vacuum Gauge: Pirani Vacuum Gauge
- Interior: SUS304
- Safety device: Self-diagnosis function (temperature sensor disconnection), refrigerator overload prevention device, refrigerator high voltage switch, overcurrent/leakage breaker
- Trap tank inner size: φ 200 mm x H 300 mm
- external dimensions : W 700 mm x D 550 mm x H 935 mm
- External output signal terminal: for recorder (temperature: 1 °C/mV, vacuum: 1 Pa/mV)
- External power supply Port: Max.3A for Driver Chamber
- power supply (50Hz/60Hz): 200 VAC Single-phase 12 A
- Required power supply Equipment: 200 VAC Single-Phase 15 A
- Mass (approx. kg): 140
