3-3952-11 ［Discontinued］Fume Hood Standard (open-type epoxy top board) 1200 x 830 x 2250mm ABS-1200
Product Description
Product Model: 3-3952-11Product Brand: AS ONE Corporati […]
Contact Us
Product Details
Product Model: 3-3952-11
Product Brand: AS ONE Corporation
Features
- It is a type combined with an open trestle. The trestle is an open type and convenient to combine with equipment such as a cooling water circulator or vacuum pump.
- An air volume display function is standard, allowing you to check and work on the exhaust status.
- The work surface is an epoxy top plate with excellent chemical resistance and cost performance.
Spec
- Specifications: Standard
- external dimension (mm): 1200 x 830 x 2250
- inner size (mm): 950 x 605 x 1200
- Weight (About kg): 270
- Exterior: Steel (powder coating finish)
- Interior: chemical resistant Heat-Resistant Board (Flame-Retardant material/phenolic laminated sheet or glass fiber mixed polyester)
- Work Plane: Epoxy Plastic top board Integral Part (32 mm Atsushi)
- Lifting sash: tempered glass (5 mm Atsushi) with balance weight opening restriction key (400 mm Height), Handle/ABS Plastic
- Hydrant: chemical coating Remote Operated Water Connection G 1/2 (Stop Female thread)
- drain port: Plastic Drainage connector 40 A socket with a built-in sink and trap
- Outlet: AC100V -15 A2 grounded
- lighting: Hf fluorescent lamps
- Operating Switch: Touch Panel Lighting/Fan
- Safety Function: Exhaust Air air volume Display
- Exhaust Connections: PVC (Plastic vinyl chloride ) with Volume Damper Phase Flanged
- power supply connection part: Terminal block with electric box
- *Shipping, carrying-in, installation, assembly, etc. are required separately. Please contact us.
- *Exhaust fan is not included.
- exhaust
- Work Sash Opening Height (mm): 400
- Controlled wind speed (m/s): 0.5
- air volume (m3/min): 12
- Duct Connector: 200 A
- Required duct diameter (Φ mm): 200
- ancillary equipment
- Plumbing (place): 1
- 2 x fluorescent lamps 16 W
- Outlet (place) 2
