3-6241-01-20 ［Discontinued］RotoMeter with Calibration Certificate TM-4100
Product Description
Product Model: 3-6241-01-20Product Brand: AS ONE Corpor […]
Contact Us
Product Details
Product Model: 3-6241-01-20
Product Brand: AS ONE Corporation
Features
- In addition to non-contact rotation speed measurement, contact type rotation speed measurement and speed measurement are also possible using a contact type adapter (sold separately).
Spec
- Measuring range: non-contact/30 ~ 99990 rpm, contact/15 ~ 19999 rpm, speed/1.5 ~ 1999.9 m/min
- Resolution: 30 ~ 9999 rpm/(+/- 0.5% rdg + 1 dgt), 10,000 ~ 19999 rpm/(+/- 0.5% rdg + 2 dgt), 20,000 to rpm/(+/- 0.5% rdg + 20 dgt),
- Measurement accuracy: 30 ~ 199.99/0.01 rpm, 200 ~ 1999.9/0.1 rpm, 2000 to 19999/1 rpm, 20,000 to/10 rpm
- Measuring distance: 40 ~ 500 mm (when using reflective tape)
- Sampling time: 62.5 ms to 2 s
- Size: 186 x 76 x 36 mm
- Weight: approximately 200 g
- Reflective tape size: 120 x 30 mm
- Power supply: 006P9V battery x 1 (included for testing)
- *For contact ***, an optional adapter (3 -6241 -11) is required.
