Spec

• Round Flask 10 L (Aperture 100 mm)
• Speed range: 10 ~ 120 rpm continuously variable
• Evaporation capacity: Max. 3.5 L/h (evaporation of water)
• Reached vacuum: 2.6 hPa (2 Torr) or less
• Temperature control range: room temperature + 10 ~ 180 degrees C (for both water and oil)
• Temperature control accuracy: +/- 1 degrees C (when using water and rotating the sample flask), +/- 3 degrees C (when using oil and rotating the sample flask)
• Temperature control: P.I.D control
• Safety features: Overflow tube, indep***ent overrise protector, bus lift limit switch, motor f***, ground fault breaker
• Display function: bath temperature, sample flask rotation speed, digital display
• Bus jack function: electric auto jack
• Vacuum control functions: constant value control (1 ~ 760 mmHg/1 ~ 1013 hPa), program control (internal setting for each representative solvent), auto control (temperature sensor optional), step control
• Heater: 3.5 kW for temperature control
• Motor: Induction motor output 60 W
• Cooler: Vertical triple serpentine, cooling area: 0.5 m2
• Receiving flask: Round flask 5L (with drain valve)
• Vacuum Seal: Teflon (R) Seal
• Inside Bus Dimensions/Capacity/Material: Inner diameter 360 x 200 mm/20 L/SUS 304
• Connection diameter: outside diameter of suction nozzle: 16 mm, outside diameter of cooling water nozzle: 16 mm, vacuum controlled solenoid valve: outside diameter of connection nozzle: 13 mm
• Bass jack stroke: 145 mm
• Operating ambient temperature range: 5 ~ 35 degrees C
• External dimensions: 930 x 450 x 1890 mm
• Weight: 96 kg
• Power input/voltage: 19 A, 3.8 kVA/200 V AC single-phase 50/60 Hz/* Power plug not included.
• Power utility: 200 VAC single-phase 30 A capacity
• *Performance is measured at room temperature of 20 degrees Celsius and rated supply voltage.
• Code: 248100
